DS81L is the new low power barebone media centre from Shuttle
Shuttle, pioneer in small form factor desktops announced DS81L barebones media player, powered by Intel’s CPUs. With a maximum power usage of 84W, DS81L supports dual disply FullHD or single display Ultra HD video. Whilte one can get a basic Celeron CPU, the configuration can be upped to include a Core i7 for blazing speed., upto 16GB of 1600MHz DDR3 memory can be installed.
DS81L comes with dual USB 3.0 ports, four USB 2.0 ports, dual LAN ports, dual DisplayPorts, one HDMI port and two COM ports. Those who use older VGA connector for display can get an accessory PVG01 that can be connected to the motherboard. DS81L will be available soon globally and the price is not yet revealed.
Specifications
| FORM FACTOR | 1.3L chassis |
|---|---|
| PROCESSOR | Support Intel Haswell Core i3/i5/i7 CPU |
| CHIPSET | Intel H81 Express chipset |
| MEMORY | 2 x 204 pin DDR3 SODIMM slots,8GB per DIMM (Max 16GB) Dual Channel DDR3 1600 Mhz |
| VGA | HDMI + Display port dual display |
| AUDIO | Realtek ALC892 channel High Definition Audio |
| ETHERNET | Realtek 8111G X2 100Mb/s and 1Gb/s operation Support Wake-On-LAN function |
| STORAGE INTERFACE | SATA 3 6.0GB/S interface SATA 2 3.0GB/S interface |
| ONBOARD CONNECTORS | (1) SATA 6 connectors (1) SATA 3 connector (1) SATA power connector (1) LPC header (1) 4pin fan connector (1) D-sub connector |
| FRONT PANEL | (4) USB 2.0 ports (1) Microphone-In (1) Earphone-Out (1) Power-On button (1) Power LED (1) HDD LED (1) SD Card reader |
| BACK PANEL | (2) RJ45 Gigabit LAN port (2) Display port (1) HDMI port (2) USB 3.0 ports (2) USB 2.0 ports (1) RS232 (1) RS232/RS422/RS485 (1) Clear CMOS (1) External power on header (1) DC in (1) Kensington lock (2) Wireless Antenna fixture |
| DRIVE BAYS | (1) 2.5″ HDD / SSD bay |
| DIMENSIONS | 190(L) x 165(W) x 43(H) mm |
| POWER | 84W Power Adapter Input:100- 240V AC Output: 12V 7A DC |
| ACCESSORIES | XPC Multilanguage Quick User Guide XPC DVD Driver VESA mount VESA mount quick installation guide 1* Power cord 1* SATA cable Screws Optional 802.11b/g/n WLAN module |
| EXPANSION SLOT | (1) Full size Mini-PCIE socket (Only support m-SATA ) (1) Half size Mini-PCIE socket |
| OS SUPPORT | Windows 8.1 Windows 7 Linux |
